DIMENSIONS
9-1/2″ diameter x 9″ height.
CONSTRUCTION
Spun-aluminum shade, acrylic diffuser. 5″ diam. x 1/2″ deep canopy. For standard ceiling junction box mounting. UL listed, cUL (ETL/ETLc for LED) certified for dry locations.
LAMPING/WATTAGE
Fixtures supplied less lamps. Lamps may be ordered from d’ac.
1M60 60W max, medium base, A type
LED8* 800 total lumens. 80CRI (default) or 90CRI (optional)
LED15* 1500 total lumens. 90CRI
LED20* 2000 total lumens. 90CR
*Color Temperature Options: 2700, 3000K (standard), 3500K, and 4000K
VOLTAGES
120 120V
277 277V
FINISHES
AL Brushed Aluminum
PA Polished Aluminum
Baked Enamels
WH White Gloss
MG Metallic Grey
AN Metallic Anthracite
BZ Metallic Bronze
GM Metallic Green
RD Metallic Red
BL Metallic Blue
CU Metallic Copper
BG Black Gloss
MB Matte Black
BC Black Crinkle
T1 Light Tan
T2 Medium Tan
G1 Light Grey
G2 Medium Grey
RB Bright Red
YL Bright Yellow
SF Seafoam
MP Magenta Pink
SCF Special Finish – must supply paint chip
Download page d9000 for color renderings.
OPTIONS
EMP External Emergency Ballast
DIM 0-10V dimming driver; compatible with dedicated LED lamping. Contact d’ac for additional dimming control capabilities.
