DIMENSIONS
21-1/2″ diameter x 6-3/4″ height. 60″ overall height
CONSTRUCTION
Spun-aluminum shade, white opal acrylic diffuser. 5″ diam. x 1/2″ deep canopy. For standard ceiling junction box mounting. UL listed, cUL (ETL/ETLc for LED) certified for dry locations.
LAMPING/WATTAGE
Fixtures supplied less lamps. Lamps may be ordered from d’ac.
2M60 60W max, medium base, A type
LED12* 1200 total lumens. 90CRI
LED20* 2000 total lumens. 90CRI
LED29* 2900 total lumens. 90CRI
LED35* 3500 total lumens. 90CRI
LED40* 4000 total lumens. 90CRI
*Color Temperature Options: 2700, 3000K (standard), 3500K, and 4000K
VOLTAGES
120 120V
277 277V
FINISHES
AL Brushed Aluminum
PA Polished Aluminum
Copper Finishes
CPL Polished Copper (Lacquered)
CBL Brushed Copper (Lacquered)
CPU Polished Copper (Unlacquered)
CBU Brushed Copper (Unlacqurered)
Baked Enamels
WH White Gloss
MG Metallic Grey
AN Metallic Anthracite
BZ Metallic Bronze
GM Metallic Green
RD Metallic Red
BL Metallic Blue
CU Metallic Copper
BG Black Gloss
MB Matte Black
BC Black Crinkle
T1 Light Tan
T2 Medium Tan
G1 Light Grey
G2 Medium Grey
RB Bright Red
YL Bright Yellow
SF Seafoam
MP Magenta Pink
SCF Special Finish – must supply paint chip
Download page d9000 for color renderings.
OPTIONS
INCP Inner Shade in Raw Copper
COIL Coiled Electrical Cord
STEM Rigid 1/2″ Diameter stem
TR For Use With Track Systems
DIM 0-10V dimming driver; compatible with dedicated LED lamping. Contact d’ac for additional dimming control capabilities.
